Digital Bomb Calorimeter BCM-AC

Product Image
Product Overview

Oxygen bomb calorimeters are widely used for the determination of calorific value in a variety of samples such as coal, lignite, coke, biomass, and light diesel oil (LDO). These instruments are essential for applications in industrial, commercial, and educational laboratories, including universities and research institutions.

The ARICO BCM-AC Bomb Calorimeters are among the most reliable, stable, and accurate calorimeters manufactured in India. They deliver performance comparable to other leading manufacturers, while being available at a significantly more economical cost. With full compliance to respective standards in this category

This Bomb calorimeter model offer unique Schrader valve free design to avoid frequent breakdown in combustion vessel, a high temperature measurement accuracy of 0.001°C, ensuring precise and repeatable results. The Auto gas filling station supplied with instrument make the gas filling with single push thus becomes Gas Filling process much easier & saves time as well, the integrated software automates critical calculations, including: Maximum rise in temperature, Heat capacity of the calorimeter (Water Equivalent / Equivalent Value), Calorific value of the sample

All test results are automatically computed and stored in a structured summary format, enhancing ease of data analysis and record-keeping.

ModelBCM-AC
Operational PrincipleIsothermal
Fundamental StandardsBIS-1350 (Part-2), IP-12/63T
Inner VesselElectroplated Copper
Outer JacketWater Filled SS
Combustion Bomb ValvePin Valve type (Schader free Design)
Bomb & BucketRemovable
Oxygen FillingAutomatic
O2 Filling Time<1 Minute
Pressure RegulatorDual gauge auto settable
SensorDual
Temperature Accuracy0.001ºC
R.S.D1%-0.1% on Benzoic Acid
Range *1,000 to 9,500 Cal/g
Temperature DisplayDigital Temperature with Timer and printer for Final result
StirrerLow Heat Generating, Compact 12V DC
Bomb FiringAuto and Manual
Printer Facility (Temp Vs Time)Available
CalculationAutomatic
Testing Time12 Minutes (approx.)
MemoryAvailable
Operating Temperature15-30º C
Weight30 Kg approx.
Power Input & Requirement<0.8KW, 230V+10V, 50 Hz
  • By using spicke correction capable of measuring of low value and by reducing weight of sample can measure higher value .
  • Note: Due to process of continuous improvements, specifications are subject to change without prior notice
Note: Due to continuous improvements specifications given above can be changed without prior notice
